| Technical Data | ||
| Camera head: | · Aspect ratio: 16:9 · Image sensor: 1/3» MOS · Immersible (using the attached cap) |
|
| Voltage range (current consumption): Frequency: Device protection: |
· 100-240 V (25 VA) 50-60 Hz 2x T3,15 A |
|
| Video system: | · Image resolution: full HD 1920 x 1080 (1080p) · TV resolution: > 900 lines · Sensitivity: < 3 lux (1/1.4) · White balance automatically, with data hold shutter speed: 1/50 (1/60) to 1/10.000 sec |
|
| Connections | Video out terminal: · 1x HDMI |
Other connections: · 1 x USB (A) (USB-keyboard) · 1 x Remote IN (footswitch) · 2 x Remote OUT (video printer, video recorder,…) · 2 x RJ45 (Service) |
| Recording (optional) | · Image format: JPG 1920 x 1080 · Video format: Full HD 1920 x 1080; Mpeg-4 (H.264 Codec); Image rate 60fps · Connection: USB (A) |
|
| Protection class (acc.to IEC 60601-1): Safety class: IP code: Standard: Device classification (EU) 2017/745, annex VIII: |
· I · BF · 20 · IEC 60601-1-2 · I |
|
| Features: | · White balance, boost function · On-screen-menu · 10 user settings storable |
· 2.5 digital zoom · Freeze function · Character generator |
| Dimensions (WxHxD): Weight: |
· 360mm x 125mm x 351mm · approx.4,7 kg |
|
| Delivery contains: | · CCU, camera head with 3,05m (10ft) cable, mains cable, HDMI – DVI cable, HDMI cable, user manual |
|
